Stainless Steel Banding (304 & 316)
A versatile, corrosion-resistant stainless steel offering good strength, excellent temperature tolerance, and non-magnetic properties. Well-suited for industrial and high-heat transformer designs. Performs poorly in chloride-heavy environments and is not suitable when electrical conductivity is required.
A versatile, corrosion-resistant stainless steel offering good strength, excellent temperature tolerance, and non-magnetic properties. Well-suited for industrial and high-heat transformer designs. Performs poorly in chloride-heavy environments and is not suitable when electrical conductivity is required.
✅ Marine-grade corrosion resistance and high-temperature stability
✅ ASTM A240 & AMS5513 certified
Stainless Steel (Grade 304)
Engineering Specifications:
- Material: Stainless Steel 304
- Standard: ASTM A240
- Composition: 18% chromium, 8% nickel (Austenitic)
- Tensile Strength: 505 MPa (73,200 psi)
- Yield Strength: 215 MPa (31,200 psi)
- Corrosion Resistance: Excellent in most environments
- Temperature Resistance: Up to 870°C (1,600°F)
Reasons to Choose:
- High Corrosion Resistance: Suitable for most industrial environments
- Excellent Strength-to-Weight Ratio: Provides high mechanical strength
- Non-Magnetic: Reduces electromagnetic interference
- Good Temperature Resistance: Withstands high temperatures without losing strength
Reasons Not to Choose:
- Lower Chloride Resistance: Prone to pitting in chloride environments (e.g., marine)
- Poor Conductivity: Not ideal for applications requiring electrical performance
Applications: High-temperature transformers, general industrial use, non-marine outdoor environments
Stainless Steel (Grade 316)
Applications: Marine transformers, chemical processing environments, high-temperature industrial use
Engineering Specifications:
- Material: Stainless Steel 316
- Standard: ASTM A240
- Composition: 16% chromium, 10% nickel, 2–3% molybdenum (Austenitic)
- Tensile Strength: 515 MPa (74,700 psi)
- Yield Strength: 240 MPa (34,800 psi)
- Corrosion Resistance: Superior to 304, especially in chloride-rich environments
- Temperature Resistance: Up to 870°C (1,600°F)
Reasons to Choose:
- High Chloride Resistance: Excellent for marine and coastal environments
- Superior Corrosion Resistance: Withstands harsh chemical exposures
- High Strength and Durability: Suitable for heavy-duty applications
Reasons Not to Choose:
- Higher Cost: More expensive than 304 stainless steel
- Poor Electrical Conductivity: Not recommended for electrical applications
